Page 72 - 2026_Brochure_US

UTILITY/WORKSITE RADIOS

SG Model BB-100 TB-100 LB-100 / SG-102 U3 U4 U7HD
FM Frequency (MHz) 87.5–108 87.5–108 87.5–108 87.5–108 87.5–108 87.5–108 / 87.5–107.9 / 76–108
FM RDS/BDS - - - - PS / PTY / RT / CT PS / PTY / RT / CT / PI
TUNER
AM / MW Frequency (kHz) 522–1710 (9k) / 520–1710 (10k) 522–1710 (9k) / 520–1710 (10k) 522–1710 (9k) / 520–1710 (10k) 522–1710 (9k) / 520–1710 (10k) 520–1710 (10k) 522–1629 (9k) / 520–1710 (10k)
HD Radio - - - - - O
Weather Band Channel - - - - 1–7 (162.40-162.55 MHz) -
Memory Presets 10 (5 AM / 5 FM) 10 (5 AM / 5 FM) 10 (5 AM / 5 FM) 10 (5 AM / 5 FM) 15 (5 AM / 5 FM1 / 5 FM2) 40 (20 AM / 20 FM)
TUNING
Rotary Tuning O O O O O O
Auto Tuning System / Seek Tuning O - - O O O
Bluetooth O - - - O O
MEDIA
Aux-in O O O O O O
Version 4.1 - - - 5.2 5
Codec SBC - - - SBC / Aptx / Aptx HD SBC
NFC - - - - O O
BLUETOOTH
AVRCP Play / Pause / Previous / Next - - - Play / Pause / Previous / Next / Rewind / Forward Play / Pause / Previous / Next / Rewind / Forward
A2DP O - - - O O
TWS - - - - - O
Real Time - - - - Radio Radio
Alarm - - - 1 Set 2 Sets 2 Sets
Timer - - - - O -
CLOCK HWS (Humane Wake System) - - - - O O
Snooze - - - O O O
Sleep Timer - - - O O O
Auto Shut Off - - - - - O
Type LCD LCD LCD LCD LCD TFT LCD
Size (mm) 57 x 25 57 x 25 57 x 25 99.6 x 24.6 70 x 27.3 56.3 x 36.7
Size (in) 2.24 x 0.98 2.24 x 0.98 2.24 x 0.98 3.92 x 0.97 2.76 x 1.07 2.21 x 1.45
Graphic / Character Type Segment Segment Segment - Segment Graphic
DISPLAY Backlight O O O O O O
Dimmer - - - - - O
Battery Level Indicator O O O - O O
LED Low Battery Indicator - - - - O -
LED Charging Indicator O O O - O -
Speaker Size 127mm / 5" 127mm / 5" 127mm / 5" 165mm / 6.5" 165mm / 6.5" 165mm / 6.5"
Speaker Impedance 8 ohm 8 ohm 8 ohm 8 ohm 8 ohm 8 ohm
Speaker Output (AC / DC Powered) 4.5W 5W 5W 5W DC / 6W AC 7W 7W
Speaker Output (Battery Powered) 2W 2W 2W 4W 4W 4W
Speaker Output (Max) 15W 8W 8W 15W 15W 15W
AUDIO
Amplifier Class AB Class AB Class AB Class AB Class AB Class AB
Earphones - - - 5mW x 2 - -
Stereo - - - Earphones - -
Treble / Bass Control - - - O O O
Loudness Always on - - - Switchable Switchable
OTHER FEATURE Dust & Water Resistance IPX4 IPX4 IPX4 IPX4 IP64 IP65
Flashlight - - - O - -
OTHER
FEATURE Roll Cage Design - - - O - O
External FM Antenna - - - - Telescopic Antenna -
Other (Emergency (EAS) / - - - - - Emergency (EAS)
Aux-in (3.5mm) O O O O O O
I/O Earphone (3.5mm) - - - O - -
SOCKET USB Socket Type - - - - USB Type-A USB Type-A
USB Socket DC Out - - - - O O
AC / DC AC-in 120V AC-in 120V AC-in 120V AC-in 120V / DC-in 9-14V/1A AC-in 230V AC-in 120V / DC-in 12V/1.2A
POWER Battery 4 x C 1.5V 4 x C 1.5V 4 x C 1.5V 6 x D 1.5V 6 x D 1.5V 6 x D 1.5V
SUPPLY Battery Rechargeability O O - - O O
Backup Battery - - - O - -
Width (mm) 310.2 310.2 310.2 193.5 267.5 297.2
Height (mm) 232.5 232.5 232.5 382 341.7 341.7
Depth (mm) 193.5 193.5 193.5 262 297.2 267.5
Weight (g) 3,143 3,003 3,003 3,000 4,900 4,917
DIMENSIONS
Width (inch) 12.21 12.21 12.21 7.62 10.53 11.7
Height (inch) 9.15 9.15 9.15 15.04 13.45 13.45
Depth (inch) 7.62 7.62 7.62 10.31 11.7 10.53
Weight (lb) 6.93 6.62 6.62 6.61 10.8 10.84
72
