POCKET RADIOS

SG Model DT-120 / DT-180 / SG-110 DT-160 DT-200XA DT-210A SR-35 SR-36

FM Frequency (MHz) 87.5–108 87.5–108 87.5–108 87.5–108 87.5–108 87.5–108
TUNER
AM / MW Frequency (kHz) 522–1710 (9k) / 520–1710 (10k) 522–1710 (9k) / 520–1710 (10k) 522–1710 (9k) / 520–1710 (10k) 522–1710 (9k) / 520–1710 (10k) 520–1710 (10k) 520–1710 (10k)
Memory Presets 15 (5 AM / 5 FM1 / 5 FM2) 15 (5 AM / 5 FM1 / 5 FM2) 19 (AM / FM Mixed) 25 (10 AM / 15 FM) - -

TUNING Rotary Tuning - O - - O O

Auto Tuning System / Seek TuningO O O O - -
CLOCK Auto Shut Off O O O O - -
Type LCD LCD LCD LCD Dial Scale Dial Scale

Size (mm) 29.6 x 25 42.2 x 23.2 34 x 16 30 x 22 - -
Size (in) 1.17 x 0.98 1.66 x 0.91 1.34 x 0.63 1.18 x 0.87 - -

DISPLAY Graphic / Character Type Segment Segment Segment Segment - -
Backlight - O O - - -

Battery Level Indicator O O O - - -
LED Tuning Indicator - - - - O O

Speaker Size - - 35mm / 1.38" 36mm / 1.42" 57mm / 2.25" 57mm / 2.25"
Speaker Impedance - - 4 ohm 8 ohm 8 ohm 8 ohm

Speaker Output (Battery Powered)- - 0.06W 0.1W 0.12W 0.12W
Speaker Output (Max) - - 0.4W 0.4W 0.5W 0.3W
CLOCK
Amplifier Class AB Class AB Class AB - - -
Earphones 1mW x 2 1mW x 2 1mW x 2 1mW x 2 1mW x 2 1mW x 2

Stereo Earphones Earphones Earphones Earphones - -
Dynamic Bass Boost O O O O - -

Lock Switch O O O O - -
OTHER
FEATURE
External FM Antenna - - - - Telescopic Antenna Telescopic Antenna
Earphone (3.5mm) O O O O O O
I/O
SOCKET
External Antenna Port 3.5mm Headphone FM Antenna Jack 3.5mm Headphone FM Antenna Jack 3.5mm Headphone FM Antenna Jack 3.5mm Headphone FM Antenna Jack - -
POWER Battery 2 x AAA 1.5V 2x AA 1.5V 2 x AA 3V 2 x AAA 1.5V 2x AA 1.5V 2x AA 1.5V
SUPPLY
Earphones O O O O - -
External Antenna - - FM Wire Antenna - - -
ACCESSORIES
Hand Strap - - - - O -
Others - - Belt Clip Belt Clip - -

Width (mm) 50.3 63.2 64 61 71.9 132.6
Height (mm) 93.1 101.2 106.5 103 124.5 70.3

Depth (mm) 16.6 19.9 30 30 32.4 32.5
Weight (g) 45 71 108 108 184 163
DIMENSIONS
Width (inch) 1.98 2.49 2.52 2.4 2.83 5.22
Height (inch) 3.67 3.98 4.19 4.06 4.9 2.77

Depth (inch) 0.65 0.78 1.18 1.18 1.28 1.28
Weight (lb) 0.1 0.16 0.24 0.24 0.41 0.36
