HD RADIO™ RECEIVERS
SG Model HDR-14 / SG-108 HDR-15X / SG-114 HDR-16 HDR-18 HDR-19 HDT-20B
FM Frequency (MHz) 87.5–108 / 87.5–107.9 / 76–108 87.5–108 87.5–108 / 87.5–107.9 / 76–108 87.5–108 / 87.5–107.9 / 76–108 87.5–108 / 87.5–107.9 / 76–108 87.5–108
FM RDS/BDS PS / PTY / RT / CT PS / PTY / RT / CT PS / PTY / RT / CT PS / PTY / RT / CT PS / PTY / RT / CT PS / PTY / RT / CT / PI
TUNER AM / MW Frequency (kHz) 522–1710 (9k) / 520–1710 (10k) 522–1710 (9k) 522–1710 (9k) / 520–1710 (10k) 522–1710 (9k) / 520–1710 (10k) 522–1710 (9k) / 520–1710 (10k) 522–1710 (9k) / 520–1710 (10k)
522-1620 (9k) 522–1629 (9k) 520–1710 (10k) 522-1620 (9k) 522–1629 (9k) 522-1620 (9k) 522–1629 (9k) 522-1620 (9k) 522–1629 (9k)
DAB / DAB+ Channel Block - - - - - -
HD Radio O O O O O O
Weather Band Channel - - - - - -
Memory Presets 40 (20 AM / 20 FM) 40 (20 AM / 20 FM) 40 (20 AM / 20 FM) 20 (10 AM / 10 FM) 20 (10 AM / 10 FM) 20 (10 AM / 10 FM)
TUNING
Rotary Tuning - - - O O O
Auto Tuning System / Seek Tuning O O O O O O
Bluetooth - - - - O -
MEDIA
Aux-in - O O O O -
Version - - - - 5.2 -
Codec - - - - SBC / AAC -
BLUETOOTH
AVRCP - - - - Play / Pause / Previous / Next -
A2DP - - - - O -
Real Time Radio Radio Radio Radio Radio Radio
Alarm 2 Sets - 2 Sets 2 Sets 2 Sets 2 Sets
Timer O - - O - O
CLOCK
HWS (Humane Wake System) O - O O O O
Snooze O - O O O O
Sleep Timer O - O O O O
Type LCD LCD LCD LCD LCD LCD
Size (mm) 41 x 19 82.4 x 21.6 82.4 x 21.6 60 x 34.5 118 x 26 71 x 39
Size (in) 1.61 x 0.75 3.24 x 0.85 3.24 x 0.85 2.36 x 1.36 4.65 x 1.02 2.8 x 1.54
Graphic / Character Type Segment Graphic Graphic Graphic Segment / Graphic Segment
DISPLAY Backlight O O O O O O
Dimmer O O - O O O
Adjustable Screen Contrast O O - O - O
Battery Level Indicator O - O - - -
LED Low Battery Indicator O - O - - -
Speaker Size 50mm / 2 76mm / 3 76mm / 3" x 2 76mm / 3" 89mm / 3.5" + 40mm / 1.57" -
Speaker Impedance 4 ohm 8 ohm 8 ohm x 2 8 ohm 8 ohm + 8 ohm -
Speaker Output (AC / DC Powered) 0.4W 1.5W 1.5W x 2 7W 15W + 10W -
Speaker Output (Battery Powered) 0.2W - 0.8W x 2 - - -
Speaker Output (Max) 0.2W 2W 3W 15W 25W + 10W -
Amplifier Class AB Class AB Class AB Class AB Class D -
AUDIO Earphones 2mW x 2 1.5mW x 2 3mW x 2 1mW x 2 1mW x 2 3mW x 2
Stereo Earphones Earphones Speaker / Earphones Earphones Earphones Earphones / Audio out
Treble / Bass Control - - - O O -
DRC (Dynamic Range Control) for DAB - - - - O -
Normal,Jazz,Rock,Classic,
EQ (Mode) - - - - -
Pop,News,Soft,My EQ
Loudness - - - Switchable Switchable -
Siren - O - - - -
Software Upgradability - - - - USB port -
OTHER Lock Switch O - - - - -
FEATURE
External FM Antenna Telescopic Antenna Wire Antenna Telescopic Antenna Telescopic Antenna Telescopic Antenna -
Other (Emergency (EAS) / - Emergency (EAS) Emergency (EAS) Emergency (EAS) - -
Aux-in (3.5mm) - O O O O -
Line-out / REC-out (3.5mm) - - O O - O
Earphone (3.5mm) - O O O O O
SD Card Slot - - - - - -
USB Socket Type - - - - USB Type-C / USB Micro-B -
USB Socket DC In - - - - - -
I/O USB Socket DC Out - O - - O -
SOCKET
USB Socket Audio Playback - - - - - -
USB Socket Audio Recording - - - - - -
USB Socket Software Update - - - - O -
AM Antenna Terminal, AM Antenna Terminal,
External Antenna Port - - - -
F Type FM Antenna Terminal F Type FM Antenna Terminal
Others - - - - - Coaxial Out,S/PDIF Out
POWER AC / DC DC-in 5V/0.8A DC-in 6V/2A - DC-in 12V/1.5A DC-In 19V/1.8A AC-in 120V
SUPPLY Battery 3 x AA 1.5V - 4 x C 1.5V - - -
AC Cord - - - - - O
Power Adapter O O O O O -
ACCESSORIES
Remote Controller - - - O O O
External Antenna - - - - - FM - Dipole type /AM - Loop type
Width (mm) 127.7 172.5 268.6 240 265.3 430
Height (mm) 78.5 57.8 138 117 168 75.5
Depth (mm) 34.6 142 71.2 215.8 144.1 285.6
Weight (g) 192.5 482 880 2,025 2,105 2,864
DIMENSIONS
Width (inch) 5.03 6.79 10.57 9.45 10.44 16.93
Height (inch) 3.09 2.28 5.43 4.61 6.61 2.97
Depth (inch) 1.36 5.59 2.8 8.5 5.67 11.24
Weight (lb) 0.42 1.06 1.94 4.46 4.64 6.31
